AS 1100.201

$70.00

Technical drawing, Part 201: Mechanical engineering drawing

Published by Publication Date Number of Pages
AS 11/16/1992

72
PDF FormatPDF FormatMulti-User-AccessMulti-User AccessPrintablePrintableOnline downloadOnline Download
Category:

Description

AS 1100.201 – Technical drawing, Part 201: Mechanical engineering drawing

Sets out recommendations for mechanical engineering drawing practice. Provides information on surface texture and welding, and the simplified representation of pipelines. Provides details on springs, gears, splines, rolling element bearings, seals and knurling. Appendices provide guidance on the tolerance of machined components and castings.

Product Details

Edition:
2nd
Published:
11/16/1992
ISBN(s):
072627805
Number of Pages:
72
File Size:
1 file , 610 KB
Product Code(s):
10089483, 10089493, 10089478
Note:
This product is unavailable in Ukraine, Russia, Belarus
