AS 3708.3

$39.00

Mechanical standardization of semiconductor devices – General rules for the preparation of outline drawings of integrated circuits

Published by	Publication Date	Number of Pages
AS	12/31/1988		35

Preview

Category: AS

Description

AS 3708.3 – Mechanical standardization of semiconductor devices – General rules for the preparation of outline drawings of integrated circuits

Specifies rules for the preparation of outline drawings of integrated circuits, indicating how case leads are to be numbered. Information is given on limits for dimensions, illustrations of letter symbols, terminal identification and index area, the design identification of circuit packages of the form G family and rules for such packages intended for automated handling. It is identical with and reproduced from IEC 191-3:1974 as supplemented by IEC 191-3A, 3B, 3C and 3D.
