AWS A2.4

Description

AWS A2.4 – Standard Symbols for Welding, Brazing, Nondestructive Examination

AWS A2.4:2020 presents a system for indicating welding, brazing, and nondestructive examination requirements.

The system includes provisions for the graphical representation of welds, brazes, and nondestructive examination methods with conventions for specifying, at a minimum, the location and extent of their application.Optional elements and supplementary symbols provide a means for specifying additional requirements.

The figures included with the text are intended to show how the correct format and applications of symbols may be used to convey welding, brazing, and nondestructive examination information. They are not intended to represent recommended welding, brazing, nondestructive examination, or design practice.

The clause addressing brazing uses the same symbols that are used for welding. The clause on nondestructive examination symbols establishes the symbols to be used on drawings to specify nondestructive examination for determining the suitability of components. The nondestructive examination symbols included in this standard represent nondestructive examination methods as discussed in the latest edition of AWS B1.10M/B1.10, Guide for the Nondestructive Examination of Welds. Definitions and the details for the use of the various nondestructive examination methods are found in AWS B1.10M/B1.10.

The limitations included in specifications and codes are also beyond the scope of this standard.

Product Details

Edition:

8th

Published:

01/01/2020

ANSI:

ANSI Approved

Number of Pages:

166

Note:

This product is unavailable in Ukraine, Russia, Belarus
