IPC 6012E

Description

IPC 6012E – Qualification and Performance Specification for Rigid Printed Boards

IPC-6012E specification covers qualification and performance of rigid printed boards, including single-sided, double-sided, with or without plated-through holes, multilayer with or without blind/buried vias and metal core boards. It addresses final finish and surface plating coating requirements, conductors, holes/vias, frequency of acceptance testing and quality conformance as well as electrical, mechanical and environmental requirements. IPC-6012E incorporates many new and expanded requirements in areas such as back-drilled structures, alternative surface finishes, copper wrap plating, marking inks, solderability testing, plating overhang, microsection evaluation, thermal shock and performance-based testing for microvia structures. For use with IPC-6011. Supersedes IPC-6012D.

Product Details

Published:

02/01/2020

ISBN(s):

9781951577094, 9781951577575, 9781951577544

Number of Pages:

76

File Size:

1 file , 2.7 MB

Product Code(s):

6012-STD-0-D-0-EN-E, 6012-STD-0-D-0-JP-E, 6012-STD-0-D-0-DE-E, 6012-STD-0-D-0-CN-E, 6012-STD-0-D-0-EN-E, 6012-STD-0-P-0-CN-E

Note:

This product is unavailable in Russia, Ukraine, Belarus
